Magnum GURU®

470-005100-035

DOWNLOAD REQUEST QUOTE
The Magnum GURU® Plug is a higher discharge capacity version of the standard GURU® Plug. The Magnum GURU® Plug is a self-operating thermostatic drain valve that responds to engine coolant temperature and will pop open and drain when coolant reaches the set-point (35°F or 40°F). This provides almost a full 1.2 inch bore to rapidly drain a locomotive before freeze damage can occur. Resetting and rearming the Magnum GURU® Plug is easily accomplished by simply reheating the cartridge and utilizing the slotted actuator feature with the GURU® Flag and Clip tool. This feature prevents the GURU® Plug from triggering open again while refilling the cooling system with cold water.
  • Locomotive engine cooling systems
  • Stand-by diesel heating circulators
  • Back up protection in event of shutdown
  • On-board tanks and piping
  • Exclusive Thermoloid® thermal actuator
  • Actuator sensing surface is the only wetted part
  • Design excludes cooling water chemicals and other debris from moving parts
  • Long service life: All moving parts are stainless steel
  • Available in modified 1-1/4” NPT tee or flanged tee body styles
  • Paint mask minimizes accidental paint-ins
  • Knob on cartridge for easy installation and removal even in hard to reach locations
  • Drains twice as fast as the standard GURU® Plug
  • Will not trip or dump while locomotive is running
  • Straight SAE threads and O-ring seals provide for easy field maintenance and testing
  • Easy installation
  • Completely mechanical - No electrical or air connections required
  • Not affected by air flow or air temperature - releases only when cooling water reaches set-point
  • Easy system refill
  • Slotted actuator feature prevents nuisance dumps when refilling cooling system with cold water
  • Unit automatically rearms after filling and reheating
  • Optional domed anti tamper cap eliminates ability to tamper with the valve resetting stem
Series MAGNUM TYPE-FL/FL-GX
Description MAGNUM TYPE-FL/FL-GX
Opening Temperature 35°F (1.7°C)
Closing Temperature 45°F (7°C)
Body Material Stainless Steel
Release Temperature 35°F
Isometric View Download
Front View Download
Top View Download
Side View Download
